Compare
the pathological image-left and the physiological image-right
(blinded)
<<
F:
central
gas shadows (gas-fluid
interfaces, horizontal fluid level) and there is no gas in the large bowel
H:
Adult
man, 52-years-old, severe abdominal pain, vomiting, bowel sounds are absent.
Pancreatitis in the
past.
INFO/WWW:
In
small bowel obstruction vomiting occurs earlier, distension is less and the
pain is higer in the abdomen. On AXR small bowel obstruction shows central
gas shadows (gas-fluid interfaces, horizontal fluid level) and there is no
gas in the large bowel. Small bowel is identified by valvulae conniventes
which completly cross the lumen - in contrast large bowel haustra do not cross
all the lumen`s width. Causes: Adhesions, Herniae, intususception, paralytic
ileus, tumour, gallstones In large bowel obstuction pain is more constant.
On AXR gas is ususally proximal to the blockage located.
D:
Paralytic
ileus caused by acute pancreatitis
IN
THIS PART OF THE PAGE YOU FIND SOME TEXT FIELDS WHICH CAN BE OPENED EIGTHER
STEP BY STEP (CLICK ON "HISTORY", "HELP", "FINDINGS",
"DIAGNOSIS" OR "INFO/WWW-LINKS") OR AT ONCE WITH A CLICK
ON "ALL ON" - VICE VERSA CLICK ON "ALL OFF".
If you need
a physiological image to compare click here
