Compare
the pathological image-left and the physiological image-right
(blinded)
<<
F:
some
low-density area
around the basal ganglia.
H:
:
Adult
man, 65-years-old, CCT to exclude any damage to the brain after accident with
his bicycle
INFO/WWW-LINKS
Cerebral degeneration: Cerebral atrophy can be focal, especially temporoparietal
in M. Alzheimer and can be caused by multiple sclerosis and cerebrovascular
disease (multiple small cerebral infarcts).
D:
At
bony windows there is no fracture evident (no image). At brain windows haemorrhage
was exluded. But there are some low-density areas, that means small cerebrovasclar,
lacunar infarcts around the basal ganglia.
IN
THIS PART OF THE PAGE YOU FIND SOME TEXT FIELDS WHICH CAN BE OPENED EIGTHER
STEP BY STEP (CLICK ON "HISTORY", "HELP", "FINDINGS",
"DIAGNOSIS" OR "INFO/WWW-LINKS") OR AT ONCE WITH A CLICK
ON "ALL ON" - VICE VERSA CLICK ON "ALL OFF".
If you need a physiological
image to compare click here
